The ZONESUN ZS-AFC33 is an integrated filling and capping machine specially designed for squeeze bottles and liquid packaging. Featuring an intelligent control panel, customizable conveyor system, and peristaltic pump technology, it delivers precise liquid dispensing and seamless cap placement. Built for automation, it streamlines operations in food, pharmaceutical, and chemical industries—enhancing productivity while minimizing labor demands.
Parameter
Machine Model ZS-AFC33
Machine Voltage 110/220V, 50–60Hz
Machine Power 1 kW
Production Speed 10–25 bottles per minute
Max Flow Rate 1.5 L/min
Recommended Filling Range 1–30 ml
Filling Pump Type Peristaltic Pump
Suitable Bottle Size Customized
Bottle Cap Size Customized
Air Pressure Requirement 0.4–0.6 MPa
Package Size Approx. 1760 × 1180 × 1550 mm
Package Weight Approx. 486 kg
TOUCHSCREEN CONTROL PANEL
The touchscreen allows operators to run the machine and recall saved settings for different products or production runs.
VIBRATORY BOWL SORTER
The vibratory bowl automatically sorts caps before they enter the capping process.
HYGIENIC PERISTALTIC FILLING
The liquid remains inside the tubing during filling and does not contact the pump mechanism.
ADJUSTABLE PUMP ROLLERS
The peristaltic pump roller assembly can be adjusted to suit bottles with different filling requirements.
PHOTOELECTRIC DETECTION
The photoelectric sensor detects whether a bottle is present and coordinates the machine accordingly.
ADJUSTABLE SENSOR SENSITIVITY
Sensor sensitivity can be adjusted for bottles in different colors and operating environments.
CHAIN CONVEYOR
The chain conveyor supports integration with automated packaging equipment and helps maintain efficient product transfer.
AIR SUPPLY REQUIREMENT
An air compressor is required for operation and is sold separately.
