Specification Details
Machine Model ZS-DTMP4AL Filling Machine
Power Supply 110/220V 50–60Hz, 300W
Max. Flow Velocity 5500 ml/min per nozzle (based on water)
Working Speed 20–30 bottles/min
Air Pressure 0.3–0.4 MPa
Filling Accuracy ≤ ±1% (for water)
Filling Nozzle Diameter 6 mm / 8 mm
Delay Range 0.01 – 999.9 sec
Count Range 1 – 99,999 times
Filling Volume 3 – 1000 ml
Air Compressor Connector Size OD 8 mm
Suitable Bottle Height < 220 mm (customizable up to 300 mm)
Machine Size Approx. 1110 × 580 × 1110 mm
Package Size Approx. 1150 × 610 × 1120 mm
Net Weight / Gross Weight Approx. 50 kg / 83 kg
Capping Machine
Bottle Height 60–270 mm
Bottle Caps Diameter 18–70 mm
Working Speed 20–40 bottles/min (depends on bottle & caps)
Working Voltage AC 220V/110V 50–60Hz
Working Pressure 0.4–0.6 MPa
Conveyor Length 1117 mm
Air Compressor Connector Size OD 8 mm
Machine Size Approx. 1110 × 580 × 1070 mm
Package Size Approx. 1150 × 610 × 800 mm
Net Weight / Gross Weight Approx. 67 kg / 97 kg
Machine Model ZS-FK1300 induction sealing machine
Voltage AC 220V/110V 50–60Hz
Max Power 1300W
Sealing Diameter φ10–70 mm
Suitable Bottle Height 20–300 mm
Suitable Bottle Diameter ≤ 150 mm
Max Sealing Speed 2400 bottles/hour (depends on bottle size and material)
Conveyor Size 150 mm (W) × 760 mm (L)
Cooling Method Air cooling
Machine Material Stainless steel
Machine Size Approx. 790 × 330 × 860 mm
Package Size Approx. 900 × 410 × 510 mm
Net Weight / Gross Weight Approx. 27 kg / 30 kg
CONTROL PANEL
The control panel clearly displays settings such as filling time and filling speed, allowing operators to adjust them to suit production requirements.
LIFTING FILLING NOZZLES
Four lifting filling nozzles are fitted as standard, and the filling speed and time of each nozzle can be controlled separately. This nozzle design is suitable for foamy liquids. A six-nozzle configuration can also be customized for higher production efficiency.
AUTOMATIC CAPPING
The capping unit is designed for various cap styles, including e-liquid bottle caps, spray bottle caps, and beverage bottle caps. It automatically presses and tightens the caps to improve working efficiency.
AUTOMATIC CONVEYOR
The conveyor transfers bottles automatically, helping reduce manual handling, streamline the production process, and improve operating accuracy.
ADJUSTABLE OPERATION
The control panel allows operators to adjust the conveyor speed and machine power for convenient operation.
INDUCTION SEALING
Electrified copper coils generate a strong magnetic field to seal bottles efficiently. Automatic operation helps save time and improve working efficiency.
