Especially adapt to electronic monitoring code labeling. Widely used in packaging objects, like medical, food, chemical,
cosmetics, electronic products, hardware, Auto Parts, stationeries, batteries, tape, CD, cartons and so on.
1.Using touch-screen control operating system, simple, practical, efficient;
2.Adapt variety shape of object in top labeling;
3.Screw adjustment to suppress body movements accurately;
4.Synchronization chain mechanism ensure labeling smooth and precise calibration;
5.Advanced technology of pneumatic coding system, print the batch number and expiry clearly.
6.Transmission-type rolling bottles, make sure the labels attached more firmly;
7.Labeling transparent label without bubble and wrinkle.
1.Label width: 20-150mm
4.Max Outside diameter of label roll: φ280mm
5.Inside diameter of label roll: φ76mm
6.Max Labeling speed: 200pcs /min
7.Accuracy of labeling:±1mm
8.Power: 220V/110V 50/60Hz 1200W
9.Air Pressure: 4- 6 bar or 0.4 -0.6 Mpa
10.Machine Net Weihgt : 180KG
11.Machine Dimension: 2200mm x 700mm x 1450 mm
14: Feeder Parameter: Length:280mm width:40-200mm(adjustable;height:60mm )
(THIS ONE CAN BE CUSTOMIZED and if you want the cheaper shipping cost .PLS CONTACT US )
