ZONESUN ZS-QDFM125 — Ultrasonic Cosmetic Tube Sealing Machine
🔑 Key Selling Points
- No-Heat Ultrasonic Sealing — 20 kHz ultrasonic technology bonds tubes without heating elements, eliminating burn risk and material degradation
- Integrated Cutting Mechanism — Trims excess tube material in one pass for a clean, professional finish straight off the line
- Optional Date / Batch Coding — 8-digit inline coding (3×2 mm) prints directly on the seal for full traceability without a separate printer
- Wide Tube Compatibility — Handles plastic and plastic-aluminum laminate tubes, Ø10–60 mm (standard) or Ø80–100 mm (customized), height 30–180 mm
- 10–15 pcs/min Throughput — Compact semi-automatic design that significantly reduces manual labor on cosmetic packaging lines
📋 Technical Specifications
| Parameter | Value |
|---|---|
| Model | ZS-QDFM125 |
| Power Supply | AC 110V / 220V, 50 Hz, 1,200 W |
| Ultrasonic Frequency | 20 kHz |
| Throughput | 10 – 15 pcs / min |
| Applicable Tube Material | Plastic / Plastic-Aluminum Laminate |
| Tube Diameter (Standard) | Ø10 – 60 mm |
| Tube Diameter (Customized) | Ø80 – 100 mm |
| Applicable Tube Height | 30 – 180 mm |
| Coding Format | 8 digits, 3 × 2 mm each |
| Air Connector Diameter | Ø8 mm |
| Machine Dimensions (L×W×H) | 1,000 × 500 × 1,040 mm |
| Net Weight | 67.5 kg |
| Packing Dimensions (L×W×H) | 1,070 × 530 × 770 mm |
| Gross Weight | 76 kg |
📦 Suitable Applications
Toothpaste · Hand cream · Sun cream · Shampoo · Ointment · Cosmetic & pharmaceutical soft tubes
