ZONEPACK 4 Nozzles Magnetic Pump Automatic Alcohol Hydrogen Peroxide Liquid ethanol Filler Perfume Filling Machine

Regular price $1,995.00

Parameter

​ ​

Machine model

ZS-DTMP4A

ZS-DTMP4B

Power supply

110/220V 50-60HZ

Maximum flow velocity

5500ml/min

(Each nozzle and base on water)

9000ml/min

(Each nozzle and base on water)

Working speed

20-30 bottles/min

(based on 50-1000ml filing volume)

20-40 bottles/min

(based on 50-1000ml filling volume)

Air pressure

0.3-0.4MPa

Filling accuracy

≤±1% (For water)

Diameter of Filling Nozzle

6/8mm

Delay Range

0.01-999.9s

Count Range

1-99999 Times

Filling Volume

3-1000ml(220V)3- 500ml(110V)

Size of air compressor connector

OD8mm

Bottle height

<220mm(Can be customized,max height 300mm)

Package Size

About 1110*650*420mm

About 1110*650*420mm

Gross weight

About 50.5kg

About 51.5kg



Application

This machine is suitable for filling low-viscosity liquid, such as juice, milk, soy sauce, essential oil, lotion, etc. It can be used in small production line, which can be connected with desktop capping machine and labeling machine, improving working efficiency.
