Filling Machine Automatic Membrance Pump Liquid Filling Machine
Filler Ck-280 For Oil
GFK-160 UPGRADE TYPE
GFK series CNC liquid filling machine is to use a computer for the micro water pump on the factors such as filling time, motor speed control, to achieve uniform, repetitive error minimal liquid filling way, widely used in medicine, chemical, food, beverage, grease, cosmetics and other industries, applicable to the low viscosity, no particles of liquid packing, small batch production.
The machine pumps pump body using a variety of imported materials synthesis of corrosion resistance, pump body and motor separation, no mechanical metal parts, no wear and tear in the pump body.Oil, heat resistance, acid resistance, alkali resistance, corrosion resistance, chemical resistance and other properties.This pump taking advantages of self-priming pump and chemical pump, self-priming function, thermal protection, smooth operation, long continuous idling, long continuous running load, etc.
Single-chip microcomputer control, stainless steel shell, in line with the GMP requirements.
LCD liquid crystal display, touching panel operation more convenient and simple.
Discharging mouth drip tight design, high filling precision, measurement is accurate.
Automatic counting function, effective control of filling quantity.
Name: KC-280 liquid filling machine
Power supply: 220V/ 110V
Maximum filling range: 5 ml to 3500 ml
Biggest suction Distance: 2 meter
Maximum flow speed: 3.2 L/min
Repetitive error: < 0.5%
Discharging drip tight function: YES
Power off memory function: YES
Weight: 5.5 Kg
