ZONESUN Automatic Double Lane 4 Sides Paste Filling Sealing Machine Servo Motor ZS-FS500Y-2

$20,499.00
Shipping calculated at checkout.
Voltage: 110V
Pre-sale Support Quality Guarantee About Shipping
DESCRIPTION

This servo motor VFFS packing machine can automatically finish filling material supplying, bag making, filling, sealing and date coding.Double lanes machine design improves working capacity, the sealing type can be customized according to production need.It is suitable for packaging shampoo, sauce, honey, fruit jam and ketchup.



PARAMETER
Machine model
ZS-FS500Y-2
Machine voltage
110/220V 50-60HZ 7KW
Suitable film
OPP/CPP/OPP/CE/MST/PE/PET/PE
Filling range
Customized
Filling pump
Piston pump(filling) /Diaphragm pump(feeding pump)
Lanes quantity
2(can be customized)
Film thickness
0.05-0.09mm
Sealing type
4 sides sealing(can be customized)
Film width
280-500mm
Film roll size
ID=75mm OD≤320mm
Finished Bag size(single lane)
35-60mm(W)*35-160mm(L)
Working speed
30-35 bags/min*2
Machine size
About 1700*1350*2350mm(L*W*H)
Machine weight
About 350kg
