Dual Peristaltic Pump Filling for Compatible Liquids
The ZONESUN ZS-NP2 is a semi-automatic liquid filling machine with two peristaltic pumps and gravity-assisted feeding. The dual-pump system supports simultaneous filling, while replaceable pump tubing helps simplify maintenance and product changeovers.
Material Compatibility
Suitability for viscous liquids depends on flow characteristics, temperature and compatibility with the tubing and other product-contact components. Applications such as honey, glue, oral solutions and nail polish require confirmation for the specific formulation; they are not a universal compatibility guarantee.
Key Features
- Dual peristaltic pumps for simultaneous filling.
- Control panel for adjusting filling parameters.
- Replaceable pump tubing.
- 110V and 220V options.
Technical Specifications
| Model | ZS-NP2 |
|---|---|
| Power supply | AC 110V or 220V, 50–60Hz |
| Power | 150W |
| Pump type | Peristaltic pump |
| Maximum flow rate | 1800ml/min × 2 (based on water) |
| Throughput | Approx. 6–30 bottles/min; depends on bottle, liquid, target volume and operating conditions |
| Listed filling accuracy | ±1%; actual results depend on material and operating conditions |
| Suitable bottle height | ≤90mm |
| Filling nozzle outer diameter | 5mm |
| Machine dimensions | Approx. 480 × 350 × 610mm |
| Net weight | Approx. 14.5kg |
| Package dimensions | Approx. 670 × 470 × 390mm |
| Gross weight | Approx. 24kg |
The maximum flow rate is based on water testing and does not specify the single-fill volume range. Throughput and accuracy should be verified using your actual liquid and target filling volume.
Before Ordering
Please provide the liquid type, target filling volume, bottle dimensions and bottle opening size to confirm suitability. Confirm the tubing, nozzle and supplied accessory configuration before purchase.
Machine Details
Control Panel
Set and adjust filling parameters using the control panel.
Dual Peristaltic Pumps
Two peristaltic pumps support simultaneous filling.
Tubing-Based Pumping
Within each peristaltic pump, liquid is carried inside the tubing rather than contacting the pump mechanism. Confirm the materials of all product-contact components for your application.
Gravity-Assisted Feeding
The gravity-assisted design supports compatible liquids. Confirm the feeding arrangement for your material before ordering.
